Specifications
| DIMENSIONS | 11.75″ W x 7.55″ H x .79″ D (298.5 mm W x 191.8 mm H x 20.1 mm D) |
| DISPLAY | 11.6″, 1920W x 1080H IPS; 500 nits. Optional sunlight-viewable display |
| TOUCH PANEL | 10-point Multi Touch Capacitive |
| SCREEN PROTECTION | Scratch-resistant, chemically strengthened glass |
| SCANNER | Optional High performance N6703 2D barcode scanner |
| WEIGHT | 2.7 lb. (1.23 kg) – base configuration |
| IP RATING | IP65 Sealing (water and dust) |
| DROP / SHOCK PROTECTION | MIL-STD 810G, 26 drops to 1 operating unit on to plywood over concrete from 4 feet |
| OPERATING TEMPERATURE | 32° F to +140° F (0° C to +60° C) |
| STORAGE TEMPERATURE | -27° F to +160° F (-33° C to +71° C) |
| HUMIDITY | 95% non-condensing |
| PROCESSOR | Intel® Core™ i5-8250U Processor, 6M Cache, up to 3.40 GHz |
| SYSTEM MEMORY | DDR4: 8GB RAM standard, option for DDR4: 16GB RAM |
| STORAGE | 256Gb M.2 standard, option for 512Gb M.2 SSD |
| OPERATING SYSTEM | Windows 11 Professional |
| BUTTONS | Windows® Virtual Button, volume +/-, power, barcode scanner trigger, programmable function key |
| IO PORTS | Standard: USB Type A 3.0 (2), 3.5mm Aux Power – DC Barrel Jack Standard, SIM Card Slot, MicroSD Slot |
| BATTERY | 45Wh, 11.1V, 4130mAh replaceable battery up to 7-hour battery life standard battery
Optional: 86Wh, 11.1V, 7,800mAh XL battery pack with up to 12-hour battery life. |
| AUDIO | Intel HD audio, built-in digital microphone |
| CAMERA | 8MP auto focus w/ flash (rear-facing), 2MP (front-facing) |
| LED | 3 colour LEDs for notification, power/charger, wireless |
| SENSORS | Accelerometer, gyroscope, e-compass, and light |
| APPROVALS | FCC, cUS, CE, CB, UL, IC |
| WLAN | Intel Dual Band Wireless AC 9260 Support 802.11a/b/g/n/ac |
| BLUETOOTH | BT5.0 |
| 4G LTE | Optional 4G LTE module (Mutually exclusive) |
| GPS | Optional GPS (Mutually exclusive) |
| WI-FI EXTERNAL SWITCH | Optional Wi-Fi External Antenna Switch Config (Mutually exclusive) |
| 3D CAMERA SYSTEM | Optional external 3D Camera System with Intel RealSense Depth Camera D415 |
| PART NUMBERS | TBL1680W-11: Rugged tablet with Windows 11 Pro operating system |
| WARRANTY | Three year return to base warranty as standard
Option to enhance warranty to cover accidental damage |
| VEHICLE MOUNTING OPTIONS | Powered Forklift/Vehicle Dock – Includes the following built-in ports: Serial Ports (2), Ethernet, USB (4), GPS & WWAN Connection, HDMI
Non-Powered Forklift/Vehicle Holder Magnetic Non-Powered Forklift/Vehicle Holder D Ball Mounting Kit For T16-VED-DualPort D Ball Mounting Kit For T16-HLDR RAM D Size Standard Double Socket Arm RAM Clamp Base With 4″ Max Width And 2.25″ D Ball Barrel Jack to Converter Long Cord 11-27V DC/DC Power Converter & Direct Wire Kit |
| OFFICE DOCK OPTIONS | Powered Office Dock – Includes the following built-in ports: USB (4) RS232 (1) Ethernet jack (1), HDMI port (1)
AC/DC Adapter without Power Cord (required) – North America/European/Australian |
| REPLACEMENT PARTS & ACCESSORIES | Standard Battery
XL Battery Battery Charger (2 battery bays/XL and Standard – requires power supply) Briefcase Handle Hand strap Stylus for PCT Tablets Stylus Tether Screen Protector Anti-Glare Screen Protector Detachable Backlit Keyboard |
