Specifications
| PROCESSOR | LGA1151 socket 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processor (CPU TDP max. up to 35 W) |
| CHIPSET | Intel® H110 |
| SYSTEM MEMORY | 6th gen: 2 x 260-pin SO-DIMM DDR4-1866/2133, up to 32GB, 7th gen: 2 x 260-pin SO-DIMM DDR4-2133/2400, up to 32GB |
| BIOS | AMI |
| COM | 2 x RS-232/422/485 |
| USB | 4 x USB 3.0, 2 x USB 2.0 |
| ETHERNET/POE | 4 x 10/100/1000 Mbps (Intel® i210-IT, i219-LM) |
| DISPLAY | 2 x HDMI (1 x HDMI 2.0 & 1 x HDMI 1.4b), 1 x DisplayPort |
| DIGITAL I/O | N/A |
| AUDIO | 1 x Audio (Mic-in/Line-out) |
| STORAGE | 1 x 2.5” SATA HDD drive bay (max. up 15 mm height), 1 x mSATA (enabled in BIOS setting) |
| EXPANSION | 2 x Full-size PCI Express Mini Card slot (USB + PCI Express signal), 1 x SIM slot
1 x PCIe x4 slot or 1 x PCI slot, 1 x Internal USB Type A for license dongle kit usage |
| OTHERS | 4 x SMA type connector opening for antenna, 1 x Phoenix type VDC power input connector, 1 x ATX power switch, 1 x Remote power switch, 1 x ATX/AT quick switch, 1 x Reset button, 1 x Flexible I/O window (default: 2 x DB9 half cut bracket) |
| POWER SUPPLY | 9 to 36 VDC |
| WATCHDOG TIMER | 255 levels, 1 to 255 sec. |
| CONSTRUCTION | Aluminium extrusion and heavy-duty steel, IP40 |
| OPERATING TEMPERATURE | -40°C to +50°C (-40°F to +122° F) (with W.T. SSD/DRAM) |
| RELATIVE HUMIDITY | 10% to 90%, non-condensing |
| VIBRATION | 3 Grms with SSD (5 to 500Hz, X, Y, Z directions) |
| DIMENSIONS (W X D X H) | 280 x 190 x 76 mm (11.02″ x 7.48″ x 2.99″) |
| WEIGHT (NET/GROSS) | 3.8 kg (8.37 lb)/4.6 kg (10.14 lb) |
| CERTIFICATIONS | CE, FCC Class A |
| OS SUPPORT | Win 10 IoT, Linux |
| MOUNTING | Wall mount, DIN-rail |
| PART NUMBERS | AES700-891-PCIE: Fanless embedded system with LGA1151 socket 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processor
AES700-891-PCI: Fanless embedded system with LGA1151 socket 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processor |
| OPTIONS | 3G/LTE module, Wall mount kit, DIN-rail kit, 24V 120W power adapter, CANbus PCI Express Mini module, LAN PCI Express Mini module, COM PCI Express Mini module, DIO PCI Express Mini module |
