Specifications
| DIMENSIONS | 7.28″ W x 3.66″ H x 0.81″ D (185mm W x 93mm H x 20.7mm D) |
| DISPLAY | 5.98″ 720W x 1280H LCD; 430 nits |
| TOUCH PANEL | 5 Point Touch Capacitive |
| SCREEN PROTECTION | Oleophobic, scratch-resistant glass |
| WEIGHT | 0.84 lb. (380 g) – base configuration |
| IP RATING | IP65 sealed for Water and Dust protection |
| DROP / SHOCK PROTECTION | MIL-STD 810G, (4′ drop) |
| OPERATING TEMPERATURE | 14° F to +122° F (-10° C to +50° C) |
| STORAGE TEMPERATURE | -4° F to +158° F (-30° C to +70° C) |
| HUMIDITY | 95% non-condensing |
| SENSORS | E-compass, G-Sensor, Light Sensor, Proximity Sensor |
| PROCESSOR | MT8735b Quad Core |
| SYSTEM MEMORY | 2Gb |
| STORAGE | 16Gb |
| OPERATING SYSTEM | Enterprise-Ready later generation Android 8.1, GMS (Google Mobile Services) certified and GMS EU and EEA ready. |
| BUTTONS | Home, Barcode scan (X2), volume +/-, power |
| IO PORTS | Micro USB 2.0
TF Slot – Max 128GB Micro SIM Card Slot 3.5mm Standard Earphone Jack |
| BATTERY | 5000mHA/3.7V, 8-hour battery life at 50% volume, default brightness & 1080P video |
| AUDIO | Mediatek on board chipset |
| CAMERA | 8MP, auto focus w/ flash (rear-facing)
Integrated barcode scanning as standard |
| BARCODE READER | Integrated 2D Honeywell 3680 imager standard |
| APPROVALS | FCC, CE, IC |
| WLAN | Wi-Fi 802.11 (a/b/g/n) 2.4/5.0Ghz Dual Band |
| BLUETOOTH | BT4.0 (BLE) |
| GPS | Dedicated GNSS Receiver: GPS/GLONASS/Beidou/Galileo Built-in calibration for PVT variation Supports external LNA |
| HANDLE | Optional SCAN HANDLE with two rechargeable batteries & two charging cables supplied |
| OFFICE DOCK | Optional OFFICE DOCK with two USB2.0 ports and one Ethernet port |
| OTHER OPTIONS | Optional extra battery, screen protector, hand strap |
| WARRANTY | One year return to base warranty as standard
Option to extend warranty to two year return to base |
