ROC286 1U Fanless systems
- 1U Industrial silent fanless system
- Supports 9th Gen Intel® Core™ i3/i5/i7
- Intel® Q370 chipset with RAID support
- Up to 64Gb of DDR4 memory
- NVMe PCIe x4 expansion slot
- 9~36V DC wide range power input
- Redundant AC or DC power supplies
Description
The ROC286 series is a robust 1U rackmount industrial computer, designed for demanding commercial and industrial applications like process control and intelligent automation. 1 Powered by 9th Generation Intel® Core™ processors (i3, i5, i7), it supports up to 64GB of DDR4 memory, ensuring high performance. Storage flexibility is provided by two hot-swappable 2.5” SATA SSD bays and an NVMe M.2 slot.
Our fanless 1U server systems are extremely reliable and enable silent operation due to the lack of fans or moving parts, making them ideal for a wide range of applications.
Connectivity is comprehensive with dual LAN, DisplayPort, HDMI, USB 3.1, USB 2.0, and RS232/422/485 ports. Expansion slots include PCIe x16, mPCIe, and M.2 for further customisation. The system is designed for reliability in harsh environments, meeting MIL-STD-810G standards for temperature, humidity, and shock. It operates in a wide temperature range (-20°C to 70°C, depending on configuration) and features a fanless design with an aluminium alloy heatsink.
1U fanless computers are suited for use in data centres, industrial control systems, network appliances, and other space-constrained applications. They are also extremely efficient, requiring less power than traditional computer systems, which may help you to reduce the cost of your energy.
All of our 1U fanless rackmount PC systems are constructed with high-quality components and extensively tested to provide dependable performance in even the most demanding conditions.
At Industrial Computers, we are dedicated to providing high-quality computing solutions that fulfil our clients’ demands. 1U systems are ideal whether you require a tiny, silent system for your home office or a powerful computing solution for your business. Contact us today to find out more about our products and how they may help your business.
Specifications
| PROCESSOR | Intel® Core™ i3-9100TE
Intel® Core™ i5-9500TE Intel® Core™ i7-9700TE |
| CHIPSET | Intel® Q370 |
| SYSTEM MEMORY | DDR4 up to 64GB |
| STORAGE | 2 x 2.5” hot-swappable SATA SSD easy swap trays
1 x Gen 3.0 (PCIex4) NVMe M2.2280 |
| POWER INPUT | 9V ~ 36V DC
100V ~ 240V AC |
| REDUNDANT POWER | The below models all support redundant power supplies:
ROC286AA ROC286BB ROC286CC |
| EXPANSION SLOTS | 1 x PCIe x16
1 x mPCIe 1 x M.2 2230 (E) |
| I/O PORTS | 2 x RJ45
2 x Display Port 1 x HDMI 1 x Mic, 1 x Line-Out 2 x RS232/422/485 4 x USB 3.1 2 x USB 2.0 |
| TESTING | MIL-STD-810G tested
Method 507.5, Procedure II (Temperature & Humidity) Method 501.5, Procedure I (Storage/High Temperature) Method 501.5, Procedure II (Operation/High Temperature) Method 502.5, Procedure I (Storage/Low Temperature) Method 502.5, Procedure II (Operation/Low Temperature) Method 503.5, Procedure I (Temperature shock) |
| OPERATING TEMPERATURE | Without Graphics Card (ET: -20°C to 60°C; UT: -30°C to 70°C)
With Graphics Card (0°C to 50°C) |
| STORAGE TEMPERATURE | -40°C to 85°C |
| RELATIVE HUMIDITY | 5% to 95%, non-condensing |
| VIBRATION | 5Hz~500Hz / 1Grms / 3 axis |
| DIMENSIONS (W x D x H) | 430 x 450 x 44.4 mm |
| WEIGHT | 8.5Kg |
| CHASSIS | SECC |
| HEATSINK | Aluminium Alloy, Corrosion Resistant |
| FINISH | Anodic aluminium oxide |
| APPLICATIONS | Commercial and Industrial Platforms, Embedded Computing, Process Control,
Intelligent Automation and manufacturing applications |
| CERTIFICATIONS | CE, FCC |
| OS SUPPORT | Windows 10 64Bit
Ubuntu13.04 Ubuntu13.10 Ubuntu14.04 Fedora 20 |
| OPTIONAL EXPANSION MODULES | PCIe 4 x PoE+
PCIe 2 x 10G SFP+ PCIe 4 x RJ45 PCIe 4 x COM ports |
| MODEL NUMBERS | ROC286A: 1U fanless system, DC input
ROC286B: 1U fanless system, AC input ROC268AA: 1U fanless system, Redundant DC input ROC286BB: 1U fanless system, Redundant AC input ROC286CC: 1U fanless system, DC input, Anti-Corrosion Conformal Coating |
