MILTECH 404 – INTEGRATED SOLDIER POWER AND DATA MANAGEMENT SYSTEM (ISPDS) WITH INTEGRATED SOM
The MILTECH404 outfits soldiers in the digital battlefield with a lightweight, fully integrated infantry combat ISPDS system. Techaya offers a range of lightweight adaptable systems that are ideally suited for frontline forces in the most complex modern battlefield scenarios.
Specifications
| Product Model | MILTECH 404 |
| Management | Managed |
| Ports | • 1 x 10/100 (Fast Ethernet) port • 3 x USB 2.0 ports • 1 x Serial, RS-232 • 1 x External power source input (including SMBUS V.2.0),internal charger |
| IMMERSION | IP68 |
| DIMS | 117mm x 123.2mm x 25mm |
| Connector | Power and communication connectors according to netwarrior, 6 PIN arrangement. |
| Weight | 300g |
| Operating Temp | -45C to +85C (-45F to +185F) |
| MIL-STD | MIL-STD-461E, MIL-STD-810F, MIL-STD-1275 |
| Power | Power Input: – 2 x Battery: 8-18Vdc (compatible with 3 and 4 cells smart batteries, including SMBUS per battery). – External Power: 18-28Vdc for battery charging and full system operation, • Power Output: – 5 x 5VDC, per port – Vbat (8-18Vdc), 3A per port • Total System Current Limitation: Vbat, 5A can be adjustable up to 8A. • Total System Current Limitation for 5VDC Rail: 5VDC, 5A • Total System Power Consumption: 15W |
Please download datasheet below for full product information
