KBox C-102 – Embedded Box PC
- Based on 6th Gen Intel® Core™ or XEON® E3-1500 for demanding control applications
- Modular approach – Forever Young
- Maintenance-free design
- Security Solution Kontron APPROTECT based on WIBU Systems technology
- Highest flexibility and expansion capabilities
Description
POWERFUL INDUSTRIAL COMPUTER PLATFORMS BASED ON COM EXPRESS® WITH 6TH GENERATION INTEL® CORE™ OR INTEL® XEON® PROCESSOR
Kontron’s KBox C-102 series is designed for the industrial control cabinet environment. Based on COMe modules the systems are highly scalable and ensure simple upgrades whenever needed. The availability of different housing options guarantees mounting even when space is limited.
The KBox C-102 series is based on high-performance processors with Intel® 6th Gen Core™ or Intel® XEON® E3. With its broad range of interfaces, various storage capabilities and expansion slots, the KBox C-102 series maximizes flexibility and eases adaptation to the specific application needs. In addition, integrating standard components, such as PCIe and miniPCIe cards, system expansions can be carried out quickly while allowing developers a greater degree of flexibility.
Specifications
| PROCESSOR | 6th Generation Intel® processor via COM Express® type 6: – Xeon® E3-1515M: Quad-Core 2.8 GHz, 8 MByte cache – Core™ i7-6820EQ: Quad-Core 2.8 GHz, 8 MByte cache – Core™ i5-6442EQ: Quad-Core 1.9 GHz, 6 MByte cache – Core™ i3-6102E: Dual-Core 1.9 GHz, 3 MByte cache – Celeron® G3902E: Dual-Core 1.6 GHz, 2 MByte cache |
| CONTROLLER | Intel® CM236 or QM170 (Core™ i5 & Core™ i7) |
| MAIN MEMORY | Up to 32 GByte DDR4 RAM, non-ECC/ECC |
| REAL TIME CLOCK | High-precision RTC with gold-cap backup |
| INTERFACE | 3x 10/100/1000 MBit/s Ethernet with IEEE1588 support
2x USB 3.0, 2x USB 2.0 1x DisplayPort 1x RS232 8x LEDs (Thermal, Drive, SD, Watchdog, 4x General Purpose) 2x Buttons Power/Reset & Rescue |
| MOUNTING | Control cabinet key holes, book size format |
| COOLING | Fanless |
| OPERATION TEMPERATURE | with Core™ i5-6442EQ 0 °C to +65 °C planned |
| TEMPERATURE | Storage: -40 °C to +85 °C (-40 °F to 185 °F) |
| TEMPERATURE/HUMIDITY | 93 % RH at 40 °C, non-condensing (acc. to IEC 60068-2-78) |
| APPROVALS | CE, CB, UL, FCC planned |
| OPERATING SYSTEM | Windows® 7, Windows® Embedded Standard 7, Windows® 8.1 Industry, Windows® 10, Linux® |
