NES-3900E-H310 Fanless System

– Core™ i7-8700T, 6 Core, 2.4GHz, 12M Cache

– Core™ i5-8500T, 6 Core, 2.1GHz, 9M Cache

– Core™ i3-8100T, 4 Core, 3.1GHz, 6M Cache

Turbo-boost disabled by default

– HDMI + DVI-D

2 x GPO status/COM1/2 TX/RX LEDs

1 x HDD access LEDs

1 x Battery low

1 x M.2

1 x Line-out and 1 x Mic-in

2 x Antenna holes

1 x External M.2 socket (M-key)

1 x SIM card holder

2 x USB 2.0 ports (500mA per each)

– COM1: RS232/422/485 auto flow control

– COM2: RS232/422/485 auto flow control

4 x USB 3.1 ports (900mA per each)

1 x DVI-D port

1 x HDMI port

2 x Intel® I210AT GbE LAN ports; supports WoL, teaming and PXE

1 x 3-pin remote power on/off switch

+9V to 30V DC input

8CH GPIO: internal pin header, support 4 x GPO and 4 x GPI, TTL 5V level

On-board TPM2.0 (SLB9665) for data encryption purpose

1 x Internal M.2 (B-key) support optional LTE

1 x 2.5″ HDD or SSD (SATA 3.0) drive bay

– Add-on card length: 169mm max.

– Power consumption: 10W/slot max.

1 x Internal mini-PCIe socket supports optional Wi-Fi/3.5G/4G LTE

Power input: +9 to +30V DC

Power adapter: optional AC to DC power adapter (24V DC, 120W)

(according to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)

Storage temperature: -20°C to 80°C

Relative humidity: 10% to 95% (non-condensing)

Shock protection:

– HDD: 20G, half sine, 11ms, IEC60068-2-27

– M.2: 50G, half sine, 11ms, IEC60068-2-27

Vibration protection with HDD condition:

– Random: 0.5Grms @ 5~500 Hz, IEC60068-2-64

– Sinusoidal: 0.5Grms @ 5~500 Hz, IEC60068-2-6

Vibration protection with SSD & M.2 condition:

– Random: 2Grms @ 5~500 Hz, IEC60068-2-64

– Sinusoidal: 2Grms @ 5~500 Hz, IEC60068-2-6

Linux Kernel 4.9

FCC Class A

Net weight: 5kg
